002440160 Obsolete

* MODUL ETITEC B 150/12,5 F Surge arrester

ETI Code:: 002440160
Function:: SPD Module
To use with:: ETITEC B F
Current type:: AC
Iimp(10/350) Impulse Current:: 12.5 kA
Nominal Discharge Current (8/20 μs) In:: 25 kA

Product

Net weight of the product: 0.7 kg
Stock unit of measure: pcs

Basic Packaging

Basic packaging quantity: 12 pcs
EAN code for a basic packaging: 3838895634638
Basic packaging weight: 0.9 kg
Basic packaging volume: 63 dm³

Transport Packaging

Transport packaging quantity: 24 pcs
EAN code for a transport packaging: 3838895634645
Transport packaging weight: 1.8 kg
Transport packaging volume: 126 dm³
Pallet quantity: 6,000 pcs
Customs tariff: 85363090

System configuration TN-C: ✓
Test class: Type 1
Mounting method: On basic element
Lightning impulse current (10/350 µs): 12.5 kA
System configuration TN-S: ✓
Voltage protection level: 1 kV
System configuration TN: ✓
Number of poles: 1
System configuration TT: ✓
Signalling at the device: Optical
Max. continuous voltage AC: 150 V

ETIM Classification – Version 9.0
