002440812
MOD.ETITEC M T12 400/12,5 Surge arrester
- ETI Code:
- 002440812
- Function:
- SPD Module
- To use with:
- ETITEC M T12 AC
- Current type:
- AC
- Iimp(10/350) Impulse Current:
- 12.5 kA
- Nominal Discharge Current (8/20 μs) In:
- 20 kA
21 Logistics
Product
- Net weight of the product
- 0.13 kg
- Net width
- 18 mm
- Net height
- 45 mm
- Net depth
- 82.14 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 1 pcs
- EAN code for a basic packaging
- 3838895985099
- Basic packaging weight
- 0.137 kg
- Basic Packaging Dimensions Height
- 99 mm
- Basic Packaging Dimensions Width
- 24 mm
- Basic Packaging Dimensions Depth
- 50 mm
- Basic packaging volume
- 0.119 dm³
Transport Packaging
- Transport packaging quantity
- 28 pcs
- EAN code for a transport packaging
- 3838895985105
- Transport packaging weight
- 3.917 kg
- Transport Packaging Dimensions Height
- 109 mm
- Transport Packaging Dimensions Width
- 352 mm
- Transport Packaging Dimensions Depth
- 115 mm
- Transport packaging volume
- 4.412 dm³
- Pallet quantity
- 4,984 pcs
- Customs tariff
- 85363090
10 ETIM
- Nominal voltage AC
- 800 V
- Test class
- Type 1 + 2
- Degree of protection (IP)
- IP20
- Mounting method
- On basic element
- Construction size
- 1 modular spacing
- Lightning impulse current (10/350 µs)
- 12.5 kA
- Number of poles
- 1
- Signalling at the device
- Optical
- Max. continuous voltage AC
- 400 V
- System configuration DC
- ✓
ETIM Classification – Version 9.0
