002440636
MOD. SM T2 PV 600/20 S Surge arrester
- ETI Code:
- 002440636
- Function:
- SPD Module
- To use with:
- ETITEC SM T2 PV
- Current type:
- DC
- Nominal Discharge Current (8/20 μs) In:
- 20 kA
2 Documents
18 Logistics
Product
- Net weight of the product
- 0.071 kg
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 1 pcs
- EAN code for a basic packaging
- 3838895878247
- Basic packaging weight
- 0.078 kg
- Basic Packaging Dimensions Height
- 99 mm
- Basic Packaging Dimensions Width
- 24 mm
- Basic Packaging Dimensions Depth
- 50 mm
- Basic packaging volume
- 0.119 dm³
Transport Packaging
- Transport packaging quantity
- 28 pcs
- EAN code for a transport packaging
- 3838895878254
- Transport packaging weight
- 2.265 kg
- Transport Packaging Dimensions Height
- 109 mm
- Transport Packaging Dimensions Width
- 352 mm
- Transport Packaging Dimensions Depth
- 115 mm
- Transport packaging volume
- 4.412 dm³
- Pallet quantity
- 6,328 pcs
- Customs tariff
- 85363090
10 ETIM
- Max. discharge surge current (8/20)
- 40 kA
- Max. continuous voltage DC
- 600 V
- Degree of protection (IP)
- IP20
- Mounting method
- On basic element
- Construction size
- 1 modular spacing
- Short-circuit breaking capacity (Isccr)
- 9 kA
- Signalling at the device
- Optical
- Category type 2
- ✓
- Nominal discharge surge current (8/20)
- 20 kA
- System configuration DC
- ✓
ETIM Classification – Version 9.0
